Description
It uses gypsum as the main material, adding fiber, bonding agents, modifiers, formed by suppressing, mixing and drying.  It has the characteristics of fire  sound insulation, heat insulation, light-weight, high-strength, small shrinkage, and the stability of small, non-aging, anti-moth-eaten. It can use nails, sawing, planning, adhesive and other methods of construction. It is widely used in ceiling, walls, interior walls,

Ingredient table

Name	Figure
Gypsum powder
Gypsum retaining paper
fiber
citric acid
starch
vesicant
others

Features :
1)The green covering paper is moisture and mold-resistance treated, therefore provides good mold resistance.
2) Very low deformation in humid environment ensures the integrity of wall and ceiling and will not affect joints. The hygro-expansion rate of the board is lower than 0.015%, just 1/10 of that of calcium silicate cement board (for which the hygro-expansion rate can reach up to 0.13%).
3)With low water-absorbtion rate, good air permeability and quick dry recovery, the board will resist cracking due to humidity change.
4)Water will not seep easily through the face, if constructed in humid seasons, thus guaranteeing the finishing quality.

Technical data:
1)Weight per unit: 9.5mm: 8.2kg/m2.
12mm: 10.3kg/m2
2)Rupture load: 9.5mm: Vertical: 513N.
                                            Horizontal: 171N.
                             12mm: Vertical: 684N.
                                            Horizontal: 213N.
                            15mm: Vertical: 781N.
                                            Horizontal: 281N.
3)Inner irradiation ratio: ≤1.0
4)Outer irradiation ratio: ≤0.1

Specifications:
Standard size: 1200*2400mm
Length :1800mm to 3600mm
Width :1200mm&1220mm
Thickness :7mm to 15mm
Edge :Square Edge and Tapered Edge

Samples:

1 Ingredients section
2 Forming section
3 Drying section
4 Trimming , stacking section
5 Decorative veneer section

- Widely used for partition systems and lining systems in civil, commercial and industrial buildings


For other size, pls contact us.

   When delivery , the boards should be piled up in the way of board-to board , then it is suitable for overseas transportation and indoor store .
   The panels could not be stored outside or in the store near water . It must be stored in a smooth , no rain leaking , no dust and good ventilated warehouse .It should avoid moisture before used . Once it was affected with damp , it should be cleaned up right away and sent it to a well area for drying up. Otherwise it may be destroyed.
   Carried by one man is prohibited . The board should be carried by two men with both hands of them and taking the long edges horizontally or taking the short edges vertically
